Green Pin® Master Link EN 1677-4 GR8

Grade 8 master link EN 1677-4

• Material: grade 8, alloy steel
• Safety factor: MBL equals 4 x WLL
• Standard: generally to EN 1677-4
• Finish: painted yellow, red or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC^b
• Note: from 50 t without flat part

Download
Catálogo

Especificações em milímetro

diameter	diameter	diameter		working	length	width	thickness	weight
	chain	chain		load	inside	inside		each
	1 leg	2 legs		limit
a		ß ≤ 45°	ß ≤ 60°		b	c	d
mm	mm	mm	mm	t	mm	mm	mm	kg
13	6 - 7	6	6 - 7	1.6	100	60	7	0.33
16	8	7 - 8	8	3.2	120	70	7	0.56
18	10	10	10	4.5	135	75	9	0.8
20	13	-	13	6.2	150	90	9	1.11
22	16	13	16	8.2	150	90	11	1.36
25	18	-	18	10.6	170	95	13	1.96
28	20	16	19	12.8	200	120	13	2.92
30	20 - 22	18	20 - 22	15.5	200	120	17	3.4
36	-	19 - 20	-	20	250	150	17	6.1
38	26	22	26	25	250	150	21	6.8
44	-	26	-	30	280	170	21	10.8
45	32	-	32	37	300	200	23	11.7
50	-	32	-	50	300	200	-	14.75
55	-	-	-	63	350	200	-	20
70	-	-	-	100	400	250	-	39
80	-	-	-	125	400	250	-	52

Especificações em polegadas

diameter	diameter		diameter		working	length	width	thickness	weight
	chain		chain		load	inside	inside		each
	1 leg		2 legs		limit
a		ß ≤ 30	ß ≤ 45°	ß ≤ 60°		b	c	d
inch	inch	inch	inch	inch	t	inch	inch	inch	lbs
¹/₂	⁷/_{32 - ¹/₄}	-	⁷/₃₂	⁷/_{32 - ¹/₄}	1.6	3 ¹⁵/₁₆	2 ³/₈	⁹/₃₂	0.73
⁵/₈	³/₈	⁷/₃₂ - ¹/₄	¹/₄ - ⁵/₁₆	⁵/₁₆	3.2	4 ²³/₃₂	2 ³/₄	⁹/₃₂	1.23
²³/₃₂	³/₈	⁵/₁₆	³/₈	³/₈	4.5	5 ⁵/₁₆	2 ¹⁵/₁₆	¹¹/₃₂	1.76
²⁵/₃₂	¹/₂	³/₈	-	¹/₂	6.2	5 ²⁹/₃₂	3 ¹⁷/₃₂	¹¹/₃₂	2.45
⁷/₈	⁵/₈	-	¹/₂	⁵/₈	8.2	5 ²⁹/₃₂	3 ¹⁷/₃₂	⁷/₁₆	2.99
³¹/₃₂	³/₄	¹/₂	-	³/₄	10.6	6 ¹¹/₁₆	3 ³/₄	¹/₂	4.32
1 ³/₃₂	³/₄	-	⁵/₈	³/₄	12.8	7 ⁷/₈	4 ²³/₃₂	¹/₂	6.44
1 ³/₁₆	³/₄ - ⁷/₈	⁵/₈	³/₄	³/₄ - ⁷/₈	15.5	7 ⁷/₈	4 ²³/₃₂	²¹/₃₂	7.5
1 ¹³/₃₂	-	³/₄	³/₄	-	20	9 ²⁷/₃₂	5 ²⁹/₃₂	²¹/₃₂	13.5
1 ¹/₂	1	³/₄	⁷/₈	1	25	9 ²⁷/₃₂	5 ²⁹/₃₂	¹³/₁₆	15
1 ²³/₃₂	-	⁷/₈	1	-	30	11 ¹/₃₂	6 ¹¹/₁₆	¹³/₁₆	23.8
1 ²⁵/₃₂	1 ¹/₄	1	-	1 ¹/₄	37	11 ¹³/₁₆	7 ⁷/₈	²⁹/₃₂	25.8
1 ³¹/₃₂	-	-	1 ¹/₄	-	50	11 ¹³/₁₆	7 ⁷/₈	-	32.5
2 ⁵/₃₂	-	1 ¹/₄	-	-	63	13 ²⁵/₃₂	7 ⁷/₈	-	44.1
2 ³/₄	-		-	-	100	15 ³/₄	9 ²⁷/₃₂	-	86
3 ⁵/₃₂	-		-	-	125	15 ³/₄	9 ²⁷/₃₂	-	115

Green Pin® Master Link Assembly EN 1677-4 GR8

Grade 8 master link assembly EN 1677-4

• Material: grade 8, alloy steel
• Safety factor: MBL equals 4 x WLL
• Standard: generally to EN 1677-4
• Finish: painted yellow, red or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC^b
• Note: from 60 t without flat part

Download
Catálogo

Especificações em milímetro

diameter	diameter		working	length	width	diameter	length	width	thickness	weight
	chain		load	inside	inside		inside	inside		each
	3/4 legs		limit
a	ß ≤ 45°	ß ≤ 60°		b	c	d	e	f	g
mm	mm	mm	t	mm	mm	mm	mm	mm	mm	kg
16	6	6-7	2.5	120	70	13	100	60	7	1.16
18	6-7	8	3.5	135	75	16	100	60	6	1.75
22	8	10	6.5	150	90	18	120	70	9	2.8
25	10	13	8.5	170	95	20	120	70	11	3.82
28	-	-	10	200	120	20	120	70	11	4.7
30	13	16	13	200	120	22	135	75	14	5.85
36	16	18-19	17	250	150	25	135	75	14	9.35
38	-	20	20	250	150	28	170	95	17	11.75
45	18-20	22	27	280	170	33	200	120	17	18.5
45	-	-	30	300	200	36	200	120	21	22
50	22	26	40	300	200	38	150	90	21	24
55	26	32	50	300	200	38	150	90	23	27
58	-	-	60	350	200	42	150	90	-	34
70	32	-	80	400	250	55	300	150	-	72
80	-	-	100	400	250	58	300	150	-	92

Especificações em polegadas

diameter		diameter		working	length	width	diameter	length	width	thickness	weight
		chain		load	inside	inside		inside	inside		each
		3/4 legs		limit
a	ß ≤ 30	ß ≤ 45°	ß ≤ 60°		b	c	d	e	f	g
inch	inch	inch	inch	t	inch	inch	inch	inch	inch	inch	lbs
⁵/₈	-	⁷/₃₂	⁷/₃₂ - ¹/₄	2.5	4 ²³/₃₂	2 ³/₄	¹/₂	3 ¹⁵/₁₆	2 ³/₈	⁹/₃₂	2.56
²³/₃₂	⁷/₃₂	⁷/₃₂ - ¹/₄	⁵/₁₆	3.5	5 ⁵/₁₆	2 ¹⁵/₁₆	⁵/₈	3 ¹⁵/₁₆	2 ³/₈	¹/₄	3.86
⁷/₈	¹/₄ - ⁵/₁₆	⁵/₁₆	³/₈	6.5	5 ²⁹/₃₂	3 ¹⁷/₃₂	²³/₃₂	4 ²³/₃₂	2 ³/₄	¹¹/₃₂	6.17
³¹/₃₂	³/₈	³/₈	¹/₂	8.5	6 ¹¹/₁₆	3 ³/₄	²⁵/₃₂	4 ²³/₃₂	2 ³/₄	⁷/₁₆	8.42
1 ³/₃₂	-	-	-	10	7 ⁷/₈	4 ²³/₃₂	²⁵/₃₂	4 ²³/₃₂	2 ³/₄	⁷/₁₆	10.4
1 ³/₁₆	-	¹/₂	⁵/₈	13	7 ⁷/₈	5 ²⁹/₃₂	⁷/₈	5 ⁵/₁₆	2 ¹⁵/₁₆	⁹/₁₆	12.9
1 ¹³/₃₂	¹/₂	⁵/₈	³/₄	17	9 ²⁷/₃₂	5 ²⁹/₃₂	³¹/₃₂	5 ⁵/₁₆	2 ¹⁵/₁₆	⁹/₁₆	20.6
1 ¹/₂	-	-	³/₄	20	9 ²⁷/₃₂	5 ²⁹/₃₂	1 ³/₃₂	6 ¹¹/₁₆	3 ³/₄	²¹/₃₂	25.9
1 ²⁵/₃₂	⁵/₈-³/₄	³/₄	⁷/₈	27	11 ¹/₃₂	6 ¹¹/₁₆	1 ⁵/₁₆	7 ⁷/₈	4 ²³/₃₂	²¹/₃₂	40.8
1 ²⁵/₃₂	³/₄	-	-	30	11 ¹³/₁₆	7 ⁷/₈	1 ¹³/₃₂	7 ⁷/₈	4 ²³/₃₂	¹³/₁₆	48.5
1 ³¹/₃₂	³/₄ - ⁷/₈	⁷/₈	1	40	11 ¹³/₁₆	7 ⁷/₈	1 ¹/₂	9 ²⁷/₃₂	3 ¹⁷/₃₂	¹³/₁₆	52.9
2 ⁵/₃₂	-	1	1 ¹/₄	50	11 ¹³/₁₆	7 ⁷/₈	1 ¹/₂	9 ²⁷/₃₂	3 ¹⁷/₃₂	²⁹/₃₂	59.5
2 ⁹/₃₂	1	-	-	60	13 ²⁵/₃₂	7 ⁷/₈	1 ²¹/₃₂	9 ²⁷/₃₂	3 ¹⁷/₃₂	-	75
2 ³/₄	-	1 ¹/₄	-	80	15 ³/₄	9 ²⁷/₃₂	2 ⁵/₃₂	11 ¹³/₁₆	5 ²⁹/₃₂	-	159
3 ⁵/₃₂	1 ¹/₄	-	-	100	15 ³/₄	9 ²⁷/₃₂	2 ⁹/₃₂	11 ¹³/₁₆	5 ²⁹/₃₂	-	203

Green Pin® Pear Shaped Link EN 1677-4 GR8

Grade 8 pear shaped link EN 1677-4

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-4
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI^b

Download
Catálogo

Especificações

for chain		working	length	diameter	width	length	width	length	width	weight
diameter		load		pin		inside	inside		outside	each
		limit
			a	b	c	d	e	f	g
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	kg
5	³/₁₆	0.8	85	6	7	64	33	109	55	0.14
6	⁷/₃₂	1.12	84	8	7	64	33	109	55	0.14
7-8	¹/₄ - ⁵/₁₆	2	101	9	9	77	40	132	69	0.34
10	³/₈	3.2	125	13	12	97	50	165	84	0.77
13	¹/₂	5.4	161	16	15	125	66	213	110	1.62
16	⁵/₈	8.2	198	20	19	154	84	262	140	2.72
18-20	³/₄	12.8	253	24	23	198	104	331	166	4.28

Green Pin® Connecting Link EN 1677-1 GR8

Grade 8 connecting link EN 1677-1

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard:EN 1677-1
• Finish: painted yellow (J), red (R) or white
• Temperature Range:-40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI^b DGUV

Download
Catálogo

Especificações

for chain		working	diameter	width	width	length	length	diameter	width	weight
diameter		load		outside	inside	inside	inside	eye	inside	each
		limit
			a	b	c	d	e	f	g
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	kg
6	⁷/₃₂	1.12	8	42	11	20	52	11	15	0.09
7-8	¹/₄ - ⁵/₁₆	2	9	53	14	20	55	13	19	0.15
10	³/₈	3.2	10	66	18	23	64	18	23	0.28
13	¹/₂	5.4	14	83	21	32	85	24	28	0.63
16	⁵/₈	8.2	17	103	25	40	105	28	34	1.16
18-20	³/₄	12.8	21	120	33	50	129	33	42	1.95
22	⁷/₈	15.5	23	143	40	55	140	37	51	2.94
26	1	21.6	26	160	45	60	153	46	57	4.12
32	1 ¹/₄	32.8	39	197	52	68	174	56	67	8.3

Green Pin® Omega Link EN 1677-1 GR8 - CO

Grade 8 omega link EN 1677-1

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-1
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI^b DGUV

Download
Catálogo

Especificações

for chain		working	width	diameter	width	length	width	length	thickness	width	width	thickness	weight
diameter		load		pin		inside	bow	outside		outside	outside		each
		limit
			a	b	c	d	e	f	g	h	i	j
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5	³/₁₆	0.8	14	6	7	26	20	53	13	41	28	6	0.07
6	⁷/₃₂	1.12	14	8	7	25	20	53	13	41	28	6	0.07
7-8	¹/₄ - ⁵/₁₆	2	20	9	9	34	24	71	16	55	32	9	0.20
10	³/₈	3.2	19	13	12	40	31	82	17	63	42	11	0.28
13	¹/₂	5.4	25	16	15	51	40	106	20	84	54	14	0.64
16	⁵/₈	8.2	32	20	19	64	48	132	25	104	68	17	1.28
18-20	³/₄	12.8	38	24	23	80	59	163	30	126	82	22	2.25

Green Pin® Sling Hook CL EN 1677-2 GR8

Grade 8 clevis sling hook EN 1677-2

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-2
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI^b DGUV

Download
Catálogo

Especificações

for chain diameter		working load limit	length	width	width opening	thickness	width	width outside	width outside	length outside	diameter pin	weight each
			a	b	c	d	e	f	g	h	i
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5	³/₁₆	0.8	76	7	26	15	20	28	72	108	6	0.29
6	⁷/₃₂	1.12	75	7	26	15	20	28	72	108	8	0.29
7 - 8	¹/₄ - ⁵/₁₆	2	95	9	30	20	24	32	87	136	9	0.58
10	³/₈	3.2	113	12	33	24	29	42	106	164	13	1.1
13	¹/₂	5.4	138	15	37	32	39	54	133	208	16	2.12
16	⁵/₈	8.2	161	19	44	40	44	68	165	240	20	3.67
18 - 20	³/₄	12.8	198	23	61	49	62	82	208	305	24	7.32
22	⁷/₈	15.5	236	25	75	54	65	97	242	350	28	10.63

Green Pin® Sling Hook E EN 1677-2 GR8

Grade 8 eye sling hook EN 1677-2

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-2
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 * MPI^b * DGUV *
• Note: from 8.2 t without flat part
* Excluding sizes 26 mm and 32 mm

Download
Catálogo

Especificações

for chain diameter		working load limit	length	diameter inside eye	width opening	thickness	width	diameter eye outside	width outside	length outside	width	thickness	weight each
			a	b	c	d	e	f	g	h	i	j
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5-6	³/_{16 - ⁷/₃₂}	1.12	84	23	26	15	20	43	72	114	10	6	0.28
7 - 8	¹/₄ - ⁵/₁₆	2	103	26	30	20	24	51	87	139	12	8	0.56
10	³/₈	3.2	128	35	33	24	29	65	106	172	15	10	1.09
13	¹/₂	5.4	152	41	37	32	39	77	133	209	18	12	1.98
16	⁵/₈	8.2	190	52	44	40	44	94	165	255	21	16	3.55
18 - 20	³/₄	12.8	237	60	61	49	62	115	208	327	28	21	7.1
22	⁷/₈	15.5	280	72	75	54	65	132	242	375	30	23	9.9
26	1	21.6	259	70	73	70	75	144	235	371	37	37	13.3
32	1 ¹/₄	32.8	299	66	87	78	89	150	281	430	42	42	21.6

Green Pin® Self Locking Hook CL GR8

Grade 8 clevis self locking hook

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 MPI^b

Download
Catálogo

Especificações

for chain diameter		working load limit	length	width	width opening	thickness	width	width outside	width outside	length	diameter pin	weight each
			a	b	c	d	e	f	g	h	i
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
7 - 8	¹/₄ - ⁵/₁₆	2	85	9	32	17	25	32	77	136	9	0.55
10	³/₈	3.2	116	12	43	24	29	42	92	168	13	1.02
13	¹/₂	5.4	153	15	47	32	34	54	111	218	16	2.01
16	⁵/₈	8.2	166	19	62	37	46	66	142	247	20	3.7
18 - 20	³/₄	12.8	215	23	74	43	57	80	185	312	24	7.59
22	⁷/₈	15.5	242	25	88	52	62	98	207	353	28	10.3

Green Pin® Self Locking Hook E GR8

Grade 8 eye self locking hook

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 MPI^b

Download
Catálogo

Especificações

for chain diameter		working load limit	length	diameter inside eye	width opening	thickness	width	width outside	width outside	length	width	thickness	weight each
			a	b	c	d	e	f	g	h	i	j
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
7 - 8	¹/₄ - ⁵/₁₆	2	113	24	32	17	25	48	77	151	13	9	0.53
10	³/₈	3.2	134	30	43	24	29	59	92	180	17	10	0.94
13	¹/₂	5.4	170	39	47	32	34	75	111	225	20	12	1.86
16	⁵/₈	8.2	207	49	61	37	46	93	142	273	22	15	3.49
18 - 20	³/₄	12.8	257	60	74	43	57	117	185	341	28	21	7.33
22	⁷/₈	15.5	290	71	88	52	62	133	207	383	31	21	9.91

Green Pin® Self Locking Hook EN 1677-3 CL GR8

Grade 8 clevis self locking hook EN 1677-3

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-3
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI^b DGUV

Download
Catálogo

Especificações em milímetro

for chain diameter		working load limit	length	width	width opening	thickness	width	width outside	width outside	length	diameter pin	weight each
			a	b	c	d	e	f	g	h	i
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5	³/₁₆	0.8	92	7	32	16	26	28	77	131	6	0.49
6	⁷/₃₂	1.12	92	7	32	16	26	28	77	131	8	0.49
7-8	¹/₄ - ⁵/₁₆	2	116	9	43	23	29	32	92	161	9	0.91
10	³/₈	3.2	143	12	47	32	35	42	111	200	13	1.77
13	¹/₂	5.4	167	15	61	37	45	54	142	242	16	3.33
16	⁵/₈	8.2	201	19	74	43	56	68	185	293	20	6.75
18 - 20	³/₄	12.8	232	23	88	51	63	82	207	341	24	9.57

Green Pin® Self Locking Hook S EN 1677-3 GR8

Grade 8 swivel self locking hook EN 1677-3

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-3
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification:2.1 2.2 3.1 MPI^b DGUV
• Note: equipped with needle roller thrust bearing to enable rotation under load

Download
Catálogo

Especificações

for chain diameter		working load limit	length	length inside	width inside	width opening	thickness	width	width outside	length	diameter	thickness	weight each
			a	b	c	d	e	f	g	h	i	j
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5 - 6	³/₁₆ - ⁷/₃₂	1.12	122	32	32	32	16	26	77	192	12	6	0.78
7-8	¹/₄ - ⁵/₁₆	2	148	39	37	43	23	29	92	231	14	8	1.39
10	³/₈	3.2	183	46	48	47	32	35	111	282	16	11	2.56
13	¹/₂	5.4	214	57	58	61	37	45	142	336	21	14	4.56
16	⁵/₈	8.2	269	65	73	74	39	56	185	416	25	17	9.37
18 - 20	³/₄	12.8	303	87	82	88	51	63	207	480	25	22	12.7

Green Pin® Self Locking Hook E EN 1677-3 GR8

Grade 8 eye self locking hook EN 1677-3

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Standard: EN 1677-3
• Finish: painted yellow (J), red (R) or white
• Temperature Range: -40°C up to +200°C
• Certification:2.1 2.2 3.1 MPI^b DGUV
• Note: from 12.8 t without flat part

Download
Catálogo

Especificações

for chain diameter		working load limit	length	diameter inside eye	width opening	thickness	width	width outside	width outside	length	width	thickness	weight each
			a	b	c	d	e	f	g	h	i	j
mm	inch	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kg
5 - 6	³/₁₆ - ⁷/₃₂	1.12	111	24	32	16	26	47	77	147	11	7	0.51
7 - 8	¹/₄ - ⁵/₁₆	2	134	29	43	23	29	57	92	176	14	7	0.91
10	³/₈	3.2	168	35	47	32	35	69	111	219	17	10	1.79
13	¹/₂	5.4	199	46	61	37	45	87	142	264	20	13	3.36
16	⁵/₈	8.2	247	59	74	43	56	111	185	328	26	16	7
18 - 20	³/₄	12.8	282	69	88	51	63	126	207	374	28	20	9.22

Produtos - Lingas de Corrente e Acessórios Grau 8 – Classic

Lingas de Corrente e Acessórios Grau 8

Green Pin® Master Link EN 1677-4 GR8

Grade 8 master link EN 1677-4

Green Pin® Master Link Assembly EN 1677-4 GR8

Grade 8 master link assembly EN 1677-4

Green Pin® Pear Shaped Link EN 1677-4 GR8

Grade 8 pear shaped link EN 1677-4

Green Pin® Connecting Link EN 1677-1 GR8

Grade 8 connecting link EN 1677-1

Green Pin® Omega Link EN 1677-1 GR8 - CO

Grade 8 omega link EN 1677-1

Green Pin® Sling Hook CL EN 1677-2 GR8

Grade 8 clevis sling hook EN 1677-2

Green Pin® Sling Hook E EN 1677-2 GR8

Grade 8 eye sling hook EN 1677-2

Green Pin® Self Locking Hook CL GR8

Grade 8 clevis self locking hook

Green Pin® Self Locking Hook E GR8

Grade 8 eye self locking hook

Green Pin® Self Locking Hook EN 1677-3 CL GR8

Grade 8 clevis self locking hook EN 1677-3

Green Pin® Self Locking Hook S EN 1677-3 GR8

Grade 8 swivel self locking hook EN 1677-3

Green Pin® Self Locking Hook E EN 1677-3 GR8

Grade 8 eye self locking hook EN 1677-3
